A vertical metal detector is used to identify metal foreign bodies in products, featuring a vertical structure. It employs advanced sensing technology to swiftly and accurately detect metal contaminants within products. With high sensitivity and reliability, it ensures product quality and process safety by detecting minute metal particles.
| Parameter Setting | L1027 | L1532 | L2032 |
| Frequency | 4 Frequencies, 50K800K | ||
| Working Mode | Dry, Wet, Salt, Aluminized Film, and Other Modes | ||
| Product Recipe Storage | 200 Groups | ||
| HMI | 7-inch Touch Screen | ||
| Operating System | Embedded RTOS | ||
| Conveyor Speed | Software Speed Control, 560 m/min | ||
| Alarm Mode | Audible and Visual Alarm / Alarm Stop / Automatic Sorting System (Optional) | ||
| Conveyor Belt Height | 800 50 mm | ||
| Conveyor Belt Material | Food-Grade PU Tape / Chain Plate (Optional) | ||
| Temperature and Humidity | 045C, 3085% RH (No Condensation) | ||
| IP Grade | Machine IP66, Motor IP67 | ||
| Material | SUS304 Stainless Steel | ||
| External Interface | USB / Network / RS232 / RS485 / 4G Remote / Unattended Line Support (Optional) | ||
| Sensitivity | Fe 0.4 mm | Fe 0.5 mm | Fe 0.8 mm |
| SUS 1.0 mm | SUS 1.2 mm | SUS 1.5 mm | |
| Fe 0.4 mm | SUS 1.0 mm |
| Detection of Metallic Contaminants in Bottles, Cans, and Jars |
Versatility: Supports multiple inspection modesdry, wet, salt-containing, and aluminum-coated productsfor diverse applications.
Multi-frequency Combination: Built-in four frequencies enabling real-time detection with dual-frequency optimization for both ferrous and non-ferrous metals.
Automatic Learning: Completes setup after two passes of qualified products, auto-calculating parameters with no manual adjustment.
Effect Suppression: Advanced algorithms reduce interference from salt or moisture content, ensuring detection accuracy.
Easy Operation: Color touchscreen with intuitive HMI, displaying four-frequency data synchronously.
Stability and Reliability: Waterproof variable-speed motors and fully sealed probe with SGS IP66 certification.
Built-in Frequency Hopping: Mitigates interference from large electrical equipment such as packaging lines, reducing false alarms.
Flexible Expansion: Embedded OS supports extensions via USB, printer, and network communication.
